Graphite Electrode UHP Shp for Eaf Lf Furnace Graphite Electrode with Nipple Graphite Materials

Graphite Electrode UHP SHP for EAF LF furnace Graphite Electrode with nipple graphite materialsGrade: RP,HP,UHPDiameter:300mm 350mm 400mm 450mm 500mm 550mm 600mm (12inch,14inch,16inch,18inch,20inch,24 inch)Length: 1800/2100/2400mmNipple: 3TPI, 4TPI, 4TPILMaterial: Made of high quality petroleum coke, needle c

Featured Products

Graphite Electrode UHP SHP for EAF LF furnace Graphite Electrode with nipple graphite materials
Grade: RP,HP,UHP

Diameter:300mm 350mm 400mm 450mm 500mm 550mm 600mm (12inch,14inch,16inch,18inch,20inch,24 inch)

Length: 1800/2100/2400mm

Nipple: 3TPI, 4TPI, 4TPIL

Material: Made of high quality petroleum coke, needle coke and coal tar pitch, appreciated by many foreign clients.



Specification



Physical Properties



Unit

RP Grade

(Dia.50-600mm)

HP Grade

(Dia.200-600mm)

UHP Grade

(Dia.200-600mm)

Electrical Resistance

Electrode

μΩ-m

8.0

7.0

6.0

Nipple

6.5

5.5

5.0

Bending Strength

Electrode

Mpa

11.0

12.0

12.0

Nipple

14.0

14.0

16.0

Elastic Modulus

Electrode

Gpa

9.0

12.0

12.0

Nipple

12.0

14.0

14.0

Bulk Density

Electrode

g/cm3

1.58

1.66

1.68

Nipple

1.70

1.72

1.73

C.T.E

Electrode

×10-6/°C

2.7

2.5

1.4

Nipple

2.5

2.2

1.3

Ash

Electrode

%

0.30

0.30

0.20

Nipple

 Applications

  • Electrodes in electric arc furnace and ladle refining furnace for steel making;
  • Electrodes in electric smelting furnace for producing industrial silicon, yellow phosphorus, corundum and so on.

Programmable properties

  • Good electrical conductivity.
  • High resistance to thermal shock
  • High mechanical strength


Graphite Electrode UHP Shp for Eaf Lf Furnace Graphite Electrode with Nipple Graphite Materials
Graphite Electrode UHP Shp for Eaf Lf Furnace Graphite Electrode with Nipple Graphite Materials
Graphite Electrode UHP Shp for Eaf Lf Furnace Graphite Electrode with Nipple Graphite Materials



Graphite Electrode UHP Shp for Eaf Lf Furnace Graphite Electrode with Nipple Graphite Materials
Graphite Electrode UHP Shp for Eaf Lf Furnace Graphite Electrode with Nipple Graphite Materials
Graphite Electrode UHP Shp for Eaf Lf Furnace Graphite Electrode with Nipple Graphite Materials
MOQ?

A:5-10Ton, support LCL.

Delivery time?

A:The delivery time is about 20-30days after receipt of payment.

Price?

A:Before inquiry us the price, pls be kindly send us the detail data of the material you need.

We will give you our best price.

Payment terms?

A:TT, LC

Trader or Manufacturer?

A: We are an ISO 14001:2004, GB/T 28001-2011 IDT OHSAS 18001:2007, ISO 9001:2008 approved manufacturer specialized in graphite electrodes dia75-700mm with different grades.

Production Capacity?

A:50000 metric tons per year.
